   BH-240 Arch Sheet Roll Forming Machine
914-650 K Type Span Curve Roof Roll Forming Machine



The drawing of BH-914-650



Main Technical Specification:
Size: 8900mm × 2230mm × 2300mm
Total Weight: about 15000KG
Total MotorPower:17.9KW
Bending power: 3.0kw+1.1kwx2;                         Sewing power: 2.2kw
Cutting power: 3.0kw;
Forming power: 7.5kw
Working Speed:  Straight sheet: 15m/min
Arch sheet: 13m/min
Sewing: 16m/min
Feeding Width: 914mm
Effective Width: 650mm
Step of rollers: 14 steps
Controlling system: PLC&Manual
Material of cutting blade: Cr12 moV
Sheet operating factor: 71.1%
Thickness of the coil: 0.6-1.5mm
Material of roller shaft: 45# steel, galvanized
Material of rollers: 45# steel, quenched with hard chrome
Type of cutting: Roll-formed and length-set cutting
Electric Standard : 380V / 50 HZ / 3 PHASES
The depth of the groove:181mm
Proper span: ≤26m
Ship Container: 40’HQ x 1





















Our roll forming machine is a mobile plant, which can directly be produced on worksite, effectively lowering the cost, shorting the construction period and improving the efficiency of engineering. Clients choose suitable machines according to different geographical conditions, different climatic environment, and different spans. The project is widely used in large-scale and mid-scale industrial construction, such as factory, warehouse, garage, gymnasium, exhibition center, cinema, theatre and so on.
